HOB SPECIFICATION

• Front left - triple-ring/wok: 3.5kW
• Front right - triple-ring/wok: 3.5kW
• Rear left - semi-rapid: 1.75kW
• Rear right - semi-rapid: 1.75kW
• Centre left gas - dual: 4.5kW
• Centre right ceramic griddle: 1.3kW

LIGHTING

• Interior halogen lights

DOOR FEATURES

• Number of glasses in door: 2
• Double glazed door
• Door opening: Drop down
• Removable door
• Removable door
• Removable inner door glass for easy cleaning
• Second oven - drop down door

ACCESSORIES

• Cast iron wok support
• 2 flat shelves
• 2 space saver shelves
• 2 grill pans with grid
• 2 grill pan handles
• LPG conversion kit included
• Aluminium pastry plate

OPTIONAL ACCESSORIES

• Griddle: RG1/E
• Catalytic liners: C5OL (main and second oven)
• Pizza stone: ACG10
• CDA cleaning cloth: ACC001
• Glass oven tray: ACG20

DIMENSIONS

• Width right cavity: 440mm
• Width left bottom cavity: 440mm
• Width left top cavity: 440mm
• Height right cavity: 330mm
• Height left top cavity: 200mm
• Height left bottom cavity: 330mm
• Depth right cavity: 410mm
• Depth left top cavity: 420mm
• Depth left bottom cavity: 410mm

TECHNICAL SPECIFICATION

• Main oven net capacity: 59L
• Main oven gross capacity: 71L
• Right oven gross capacity: 59.5L
• Second oven net capacity: 59L
• Second oven gross capacity: 71L
• Third oven net capacity: 37L
• Third oven gross capacity: 40L
• Rated gas input: 15kW
• Rated electrical power: 7.9kW
• Mains cable: No

ENERGY

• Main oven energy efficiency class: A
• Second oven energy efficiency class: A
• Third oven energy efficiency class: A

MAIN OVEN ENERGY EFFICIENCY

• Energy consumption forced air: 0.85kW
• Size of cavity classification: M
• Time to cook a standard load: 43.9mins

SECOND OVEN ENERGY EFFICIENCY

• Energy consumption conventional: 0.94kW
• Energy consumption forced air: 0.85kW
• Size of cavity classification: M
• Time to cook a standard load: 39.5mins

THIRD OVEN ENERGY EFFICIENCY

• Energy consumption conventional: 0.72kW

OTHER FEATURES

• Height adjustable feet
• Storage drawer
