Main features

• Model CVMAD60/1N
• Product code 36900946
• EAN Code 8016361970946
• Installation type Wall-mounted
• Typology Décor

Technical Features

• Connectivity None
• Frequency (Hz) 50
• Grease filter type Multilayer
• Total power of the lamps (W) 4
• Type of control Mechanical
• Number of motors 1
• Type of lamps used LED
• Voltage (V) 220-240

Programmes and functions

• Number of speed settings 3

Aesthetic

• Colour Black
• Material body BLACK+BLACK GLASS

Performance

• Air flow at at intensive or boost setting (m3/h) 0
• Min./Max. extraction rate (m3/hr) 463
• Energy Efficiency class (2010/30/EC) C
• Noise level (dB(A) re 1 pW) 65
• Power (W) <1000 W

Dimensions

• Height of product without chimney (mm) 0
• Diameter of air outlet (mm) 150
• Height of the product (mm) 760
• Width of the product (mm) 600
• Depth of the product (mm) 430
• Packaged Product Height (mm) 440
• Width of the packed product (mm) 655
• Packaged Product Depth(mm) 490
• Gross weight (kg)16.5
• Net weight (kg) 13.6
