FlameSelect® – Gain ultimate control of your flame.
Pan Supports - continuous cast-iron pan supports for maximum stability and cooking convenience.
Biomethane ready – Power your hob with renewable biomethane gas.
Sword Knobs - a better feel and easier to operate, the new knob in an attractive design
Dimensions
Height: 45 mm
Width: 918 mm
Depth: 546 mm
Design
ceramic glass surface, black
Bevelled design, stainless steel
black cast iron pan supports with protective rubber feet
Low profile burner: elegant burner design
Usage convenience
FlameSelect with 9 steps: precisely control and adjust the flame in nine defined levels.
Pan supports dishwasher safe: clean without effort in the dishwasher.
Design co-ordinated control dials: easily access dials in front with strong grip for effortless turning.
Ignition via control dials: just push and turn the dials to ignite the flame.
Burners and power
5 burner hob
Including 1 wok burner: use an extra wide power range, separately controlling two flame rings.
Left: Wok burner up to 6.1 KW (depending on gas type)
Center front: Standard burner up to 1.9 KW (depending on gas type)
Center rear: Economy burner up to 1.1 KW (depending on gas type)
Right rear: High speed burner up to 2.8 KW (depending on gas type)
Right front: Standard burner up to 1.9 KW (depending on gas type)
Safety
Flame failure safety device: prevents unwanted gas flow when flame goes out.
Installation (gas types & measurements)
Usable for: Nat gas L/LL G25/20mbar(DE)
NG H/E 20mbar, E+ 20/25mbar Natural gas H 25 mbar (HU) Natural gas L 25 mbar (NL) Liquid gas G30,31 28-30/37mbar Liquid gas G30 37 mbar (PL) Liquid gas 50 mbar
Factory set for connection to mains gas
Nozzle set for LPG jets (28-30/37mbar) included. Nozzles for all other gas types can be ordered via the customer service. For nozzle change, please contact the customer service.
Dimensions of the product (HxWxD mm): 59 x 918 x 546
Required niche size for installation (HxWxD mm) : 45 x 850 x (490 - 502)
Min. worktop thickness: 30 mm
Power cord: 1.5 m
Connected load: 13.8 KW
Accessories
1 x WOK attachment ring included
